Research by: Jiří Vinopal (@vinopaljiri)
What if a trusted security component could be repurposed into an attacker-controlled kernel primitive? What if a signed Microsoft remediation driver could be instructed to execute arbitrary file and registry operations from Ring 0 – without exploits, vulnerabilities, or memory corruption?
In this publication, we present the first full reverse engineering of the Windows Defender Boot-Time Removal driver (BTR.sys
) and its proprietary transaction format. We dissect its encrypted configuration mechanism, integrity validation logic, and execution pipeline, and demonstrate how this legitimate remediation component can be transformed into a universal kernel operation engine. We introduce BTR_CLI
, a research tool that constructs valid encrypted transactions and safely exercises the driver’s functionality to demonstrate its capabilities.
Furthermore, we demonstrate how BTR_CLI
can be used as an EDR/AV bypass technique, disarming security solutions while using a trusted Windows built-in, Microsoft-signed driver, thus not relying on typical BYOVD techniques.
Our research reveals how trusted security infrastructure can unintentionally expose powerful primitives, what this means for defenders, and how similar patterns may exist in other signed remediation components. This work blends reverse engineering, kernel internals, and detection engineering into a practical case study of when defensive technology becomes offensive capability.
This research originated during an incident response investigation involving a compromised system, where certain endpoint telemetry appeared suspicious but was ultimately traced back to legitimate Windows Defender remediation activity. During analysis, a driver (internally identified as BTR.sys
) appeared on disk under System32\drivers
with a randomized filename and a corresponding randomized service name (HKLM\SYSTEM\CurrentControlSet\Services\mzqnjtaq
), accompanied by the following registry entries:
| Value Name | Value Type | Data |
|---|---|---|
| Type | REG_DWORD | 1 (Kernel Driver) |
| Start | REG_DWORD | 1 (System Start) |
| ErrorControl | REG_DWORD | 0 (Ignore) |
| ImagePath | REG_EXPAND_SZ | \\??\C:\Windows\system32\drivers\mzqnjtaq.sys |
| Group | REG_SZ | Boot Bus Extender |
| Args | REG_SZ | C:\Windows\system32\drivers\mzqnjtaq.sys:changelist |
At first glance, several characteristics resembled attacker tradecraft:
:changelist
) attached to the driver fileThese indicators strongly resembled malicious kernel loader behavior, particularly given prior research into exotic loading mechanisms such as loading kernel drivers directly from ADS paths – a technique often considered theoretical yet has proven practical.
The most unusual aspect was that the ADS stream contained an encrypted binary structure used as configuration input for the driver. Encountering a Microsoft-signed driver relying on an ADS-stored encrypted configuration immediately raised suspicion that it might be exploitable or abused by attackers. Our initial hypothesis was that the threat actor had leveraged this driver for post-exploitation activity. That hypothesis ultimately proved incorrect: the behavior was legitimate Defender remediation logic.
However, that discovery triggered a deeper analysis of BTR.sys
and the surrounding remediation architecture. What began as a false-positive investigation quickly evolved into a full reverse-engineering effort that uncovered undocumented functionality, a custom protocol, and an unexpectedly powerful kernel execution model.
BTR.sys
MpEngine.dll
. It is dropped to disk (with a randomized filename matching [a-z]{8}.sys
, e.g., mzqnjtaq.sys
) only when a remediation action requires a reboot (e.g., deleting a locked file).The driver does not expose a standard IOCTL interface. Instead, it reads a configuration blob pointed to by the Args
value in its Service Registry Key.
HKLM\SYSTEM\CurrentControlSet\Services\{Random}\Args
C:\Windows\system32\drivers\BTR.sys:changelist
) containing RC4-encrypted binary data.The configuration blob is protected by both encryption and integrity checks to prevent tampering.
.rdata
section of the driver (this key appears to be consistent across various BTR.sys
driver versions).~CRC32
).
0xEDB88320
) and initialization (0xFFFFFFFF
). However, it deviates from the standard implementation by omitting the final bitwise inversion (Final XOR) step. Consequently, the resulting value is mathematically equivalent to the bitwise inverse of a standard CRC-32 (denoted as ~CRC32
in the tables in the next section below).0xFFFFFFFF
) for every individual structure (Global Header, Global Payload, Item Header, and Item Data). This design isolates the validation of each component, effectively preventing CRC chaining manipulation where modifying one structure could impact the validity of subsequent structures.The RC4-decrypted payload (configuration blob) is a serialized list of actions. Through reverse engineering, we have mapped the structure entirely (notably, the PDB
for BTR.sys
is not provided by Microsoft).
The file starts with a fixed header that defines the session.
| Offset | Size | Field | Description |
|---|---|---|---|
0x00 | 4 | Magic | 0xFEE1DEAD (Little Endian) |
0x04 | 4 | Version | 0x00000002 |
0x08 | 4 | PayloadOffset | 0x00000010 (Relative offset from this field to the Global Payload; constant) |
0x0C | 4 | GlobalCRC | ~CRC32 of the Header (with this field zeroed) |
0x10 | 8 | TransID | Composite ID: Low 4 bytes = ~CRC32(Payload) , High 4 bytes = Size(Payload) |
The table above can be represented as the following C structure:
struct GLOBAL_HEADER { uint32_t Magic; // 0xFEE1DEAD uint32_t Version; // 2 uint32_t PayloadOffset; // 0x10 (relative offset to Global Payload) uint32_t GlobalCRC; // ~CRC32(Header) uint32_t TransID_Low; // ~CRC32(Payload) uint32_t TransID_High; // Size(Payload) };
It immediately follows the header.
\??\C:\ProgramData\...\mzqnjtaq.dat
). The driver creates this file and writes a Transaction Execution Report. This report mostly mirrors the structure of the input configuration but updates the first 4 bytes of each Item’s Data payload ([Flags]
) with the NTSTATUS code resulting from that specific operation.Following the Global Payload is a list of Operation Items.
Item Header (16 Bytes):
| Offset | Size | Field | Description |
|---|---|---|---|
0x00 | 4 | DataSize | Size of the Item Data (including padding) |
0x04 | 4 | ActionID | The operation to perform (see Section below) |
0x08 | 4 | HeaderCRC | ~CRC32 of this header (calculated with this field zeroed) |
0x0C | 4 | DataCRC | ~CRC32 of the Item Data |
The table above can be represented as the following C structure:
struct ITEM_HEADER { uint32_t DataSize; // Size of Item Data uint32_t Action; // Action ID uint32_t HeaderCRC; // ~CRC32(Header) uint32_t DataCRC; // ~CRC32(Data) };
Item Data (Variable):
The structure of the data depends on the Action ID. For complex actions (3-6), it starts with a Flags field; for simple actions (1-2), it starts immediately with the path. It generally follows:
[Flags (Optional 4 bytes)] [String 1] [String 2] ... [Padding]
[Flags]
field, the driver utilizes this reserved space to generate the feedback report. It shifts the string data by 4 bytes into this padding area to create room at the beginning of the buffer for the NTSTATUS code, avoiding memory reallocation.We have identified and implemented the following Action IDs
in the BTR_CLI
tool:
[Path]
[Path]
[Flags] [Source Path] [Dest Path]
Dest Path
is empty, this acts as a Delete operation. If Dest Path
is valid, this allows Arbitrary File Write/Move (e.g., dropping a malicious DLL into System32).[Flags] [Key Path]
[Flags] [Key Path + "\\" + Value Name]
\\
) to split the Key from the Value. Standard paths fail; specific formatting is required.[Flags] [Type] [Size] [Key Path + "\\" + Value Name] [Data]
A unique trait of BTR.sys
is its return value upon successful execution. It returns 0xC0000056
(STATUS_DELETE_PENDING
) instead of STATUS_SUCCESS
.
The driver creates a text log at \SystemRoot\Temp\BootClean.log
.
BTR_CLI
tool automatically injects an Action 1 item at the start of the transaction list targeting BootClean.log
.To obtain a comprehensive overview of different BTR.sys
driver versions, we searched public repositories such as VirusTotal and Winbindex (by locating MpEngine.dll
, which embeds the BTR.sys
driver). Using Winbindex, we identified exactly 12 different versions of 64-bit MpEngine.dll
across all available Windows 10 and Windows 11 releases.
Extracting the embedded BTR.sys
from these 12 MpEngine.dll
versions resulted in 5 unique driver builds (based on distinct SHA-256 hashes).
Combining these 5 builds with distinct BTR.sys
samples (unique SHA-256 hashes) identified on VirusTotal at the time of analysis, and after de-duplication against the Winbindex dataset, we obtained a total of 18 unique 64-bit Microsoft-signed versions (distinct Authentihashes) of the BTR.sys
driver. Analysis confirmed that all versions share the same hard-coded 256-byte RC4 key used to decrypt the transaction structure (configuration blob).
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
Furthermore, the transaction structure format is consistent across all analyzed versions and supports all identified Action IDs. This consistency makes the BTR_CLI
tool (provided in the next section) a universal, reliable, and reusable component across all tested Windows OS builds → from Windows 7 Build 7601, through Windows 8.1 and Windows 10 22H2, up to the latest Windows 11 25H2 at the time of writing (July 2026).
The BTR_CLI
tool serves as a fully functional Proof-of-Concept (PoC) demonstrating the offensive utility of the Microsoft Boot Time Removal driver (BTR.sys
). The source code implements a complete exploitation chain that mimics the native behavior of MpEngine.dll
while extending its capabilities for research and red-teaming purposes.
The tool performs the following sequence of operations:
BTR.sys
driver from the local MpEngine.dll
resource section. If the DLL is unavailable (cannot be found) or the hard-coded RC4 key inside the DLL has changed, it falls back to an embedded driver version (the latest one confirmed to be supported).Random.sys
) and writes the encrypted transaction payload directly into Random.sys:changelist
. The feedback path is similarly set to Random.sys:Random.dat
.BootClean.log
), followed by any user-defined actions (e.g., file deletion, registry modification, etc.).trigger now
): Creates a service with a randomized name and loads the driver immediately via NtLoadDriver
.trigger boot
): Configures the service with Start=1
(System) and Group Boot Bus Extender
to execute during the early boot phase, bypassing active EDR/AV protections.The source code of BTR_CLI, with its ready-to-run executables (both x64 and x86, each self-contained with the embedded BTR.sys
fallback), is available here, MIT licensed.
The BTR_CLI
tool underwent robust testing across a comprehensive range of Windows operating systems, spanning from Windows 7 Build 7601 (released in 2011), through Windows 8.1 and Windows 10 22H2, up to the latest fully updated Windows 11 25H2 (as of July 2026). Testing confirmed the tool’s ability to successfully execute all supported BTR.sys
capabilities (Action IDs) across every version. Notably, while the tool includes an embedded fallback driver, this redundancy was never required during testing; the target-specific BTR.sys
was successfully extracted from the local MpEngine.dll
in every instance. This capability allows the tool to operate without introducing external binaries, effectively avoiding BYOVD-like scenarios. These findings highlight a remarkable consistency in the internal BTR.sys
codebase – retaining the same hard-coded RC4 key and configuration structure for over 15 years.
Start=0
is ImpossibleThe operational premise of BTR.sys
suggests a capability to execute during the earliest stages of the operating system boot process. However, empirical testing confirms a hard architectural constraint: BTR.sys
cannot function as a SERVICE_BOOT_START
(Start=0
) driver.
While standard EDR kernel minifilters utilize Start=0
to register callbacks immediately upon kernel initialization, BTR.sys
was designed by Microsoft to perform file I/O operations (reading the ADS configuration and creating logs) directly within its DriverEntry
routine. During Phase 0 of the boot process, the Windows Object Manager has not yet established the SystemRoot
symbolic link (used by BTR.sys
), and the storage stack is not fully initialized. Consequently, forcing BTR.sys
to Start=0
results in immediate failure.
Therefore, the driver must be configured as SERVICE_SYSTEM_START
(Start=1
). To maximize its offensive utility, it is assigned to the “Boot Bus Extender” load order group. This configuration places it at one of the earliest practical execution slots available in Phase 1, immediately following the initialization of the filesystem (Ntfs.sys
) and the transition from the OS Loader to the Kernel I/O Manager. Notably, this configuration mirrors the exact mechanism MpEngine.dll
employs to stage the driver during a legitimate Windows Defender remediation event.
The Windows Kernel enforces a strict temporal hierarchy by scanning the ServiceGroupOrder
registry key in two distinct passes. First, the OS Loader loads all Start=0
(Boot) drivers during Phase 0. Once Phase 0 concludes, the Kernel I/O Manager scans the list again to load Start=1
(System) drivers during Phase 1. It is within this specific phase that the “Boot Bus Extender” group provides a strategic advantage. While Start=0
security filters (e.g., WdFilter
) are already active, BTR.sys
executes at the very beginning of Phase 1, effectively preempting other critical security drivers (e.g., UCPD
, WdNisDrv
) that reside in lower-priority groups like “FSFilter Activity Monitor” (see the default Windows 11 25H2 ServiceGroupOrder
):
System Reserved EMS WdfLoadGroup Boot Bus Extender <-- BTR.sys executes here (Start=1) ... (23 Groups) ... FSFilter Replication FSFilter Anti-Virus <-- WdFilter (the Group is lower, but Start=0) FSFilter Undelete FSFilter Activity Monitor <-- UCPD.sys (Start=1) ... (24 Groups) ... NDIS <-- Network Drivers ... (14 Groups) ...
This architectural positioning creates a “Golden Window” – a specific timeframe where the filesystem is writable, but high-level security services and user-mode protection agents have not yet started.
Boot-time logging via Process Monitor provided definitive proof of this execution timeline. The events captured during a reboot cycle on a fully updated Windows 11 25H2 environment revealed the following sequence. Note that while Procmon’s boot logging may introduce slight latency, the relative order of execution is architecturally deterministic and remains consistent.
Phase 0: Kernel Initialization (Start=0 Boot)
The kernel initializes the filesystem and early-launch security drivers.
2:45:28.3130411 AM
– WdBoot.sys
(Defender ELAM Boot Driver) loads.2:45:28.3130685 AM
– WdFilter.sys
(Defender Minifilter) loads.2:45:28.3130700 AM
– Ntfs.sys
(Filesystem) loads.
Phase 1: The “Golden Window” (Start=1 System)
The kernel transitions to System Start. BTR.sys
(renamed mlrmqchs.sys
for testing) executes immediately due to its “Boot Bus Extender” group.
2:45:28.6353170 AM
– mlrmqchs.sys
(BTR Driver) loads.
2:45:28.6915450 AM
– UCPD.sys
(User Choice Protection Driver) loads.
Phase 2: User Mode Initialization (Start=2 Automatic / Start=3 Manual)
The Service Control Manager (SCM) begins starting services. This occurs significantly later.
2:46:02.7308562 AM
– MpDefenderCoreService.exe
loads.2:46:02.9603201 AM
– MsMpEng.exe
(Defender Service) loads.
2:49:23.4912735 AM
– WdNisDrv.sys
(Network Inspection Driver) loads.
By exploiting this load order gap, BTR.sys
functions as a potent neutralizer for security solutions, including Microsoft Defender and potentially third-party EDRs.
WdFilter
is already loaded, the absence of the user-mode service (MsMpEng.exe
) renders it susceptible to “legal” operations performed by a signed Microsoft kernel driver. Tests confirmed the successful deletion of example protected binaries such as WdFilter.sys
, MsMpEng.exe
and WdNisDrv.sys
during boot. Since the MsMpEng.exe
service binary is removed significantly before the Service Control Manager even attempts to launch it, the security solution fails to start entirely, preventing self-healing, cloud reporting, etc.BTR.sys
, operating in kernel mode, successfully deleted critical Service Registry keys (e.g., HKLM\SYSTEM\CurrentControlSet\Services\WdFilter
) during runtime. This “blinds” the OS, preventing the WdFilter.sys
driver from loading on the subsequent reboot.WdBoot.sys
) protects the initial boot chain, its role is limited to evaluating boot-start drivers during early initialization. BTR.sys
executes in this post-ELAM environment (Start=1
), meaning it is not evaluated by ELAM-related boot-driver checks. Furthermore, even if this architectural gap did not exist, BTR.sys
carries a valid Microsoft signature, meaning it would normally pass signature enforcement, though this does not guarantee permanent trust or classification as “Known Good” in all contexts.Conclusion: The BTR.sys
driver, when manually staged to execute at the next boot, effectively bypasses the active protection stack by operating in the interval where the kernel is active but the security suite’s intelligence is dormant. Furthermore, tests demonstrated a successful Tamper Protection bypass at runtime.
The following demonstration video presents a complete “Kill Chain” scenario on a fully updated Windows 11 25H2 machine with all security features enabled. The Proof-of-Concept utilizes BTR_CLI
(BTR.sys
) to systematically dismantle the Windows Defender security stack from Ring 0, rendering the system defenseless against a known malicious sample.
The demonstration follows these specific stages:
mimidrv.sys
– part of the Mimikatz post-exploitation tool) and modify Defender registry keys using standard Administrator privileges. Both actions are immediately blocked by Windows Defender and Tamper Protection.trigger now
mode, we instruct the BTR.sys
driver to delete the Service Registry keys for the Defender Kernel Filter and the Antimalware Service. Since the operation originates from a signed Microsoft kernel driver, Tamper Protection is successfully bypassed.BTR_CLI.exe -chain -item "4|HKLM\SYSTEM\CurrentControlSet\Services\WdFilter" -item "4|HKLM\SYSTEM\CurrentControlSet\Services\WinDefend" -trigger now
trigger boot
mode, we schedule the physical deletion of the Defender binaries (WdFilter.sys
and MsMpEng.exe
). These operations execute during the “Golden Window” (Phase 1), after the filesystem is writable but before the Defender user-mode service can start or lock the files.BTR_CLI.exe -chain -item "1|C:\Windows\System32\drivers\wd\WdFilter.sys" -item "1|C:\ProgramData\Microsoft\Windows Defender\Platform\4.18.26010.5-0\MsMpEng.exe" -trigger boot
mimidrv.sys
is then extracted without detection. Finally, we demonstrate an arbitrary write primitive by moving the malicious driver into the protected System32\drivers
directory using the BTR.sys
driver.BTR_CLI.exe -a 3 -s "C:\Users\admin\Desktop\mimidrv\mimidrv.sys" -d "C:\Windows\System32\drivers\mimidrv.sys"
Because BTR.sys
is a legitimate Microsoft-signed component, signature-based blocking is ineffective. Furthermore, a well-crafted weaponization tool (like BTR_CLI
) intentionally mimics the operational footprint of the legitimate Windows Defender remediation process.
Based on telemetry analysis using Sysmon (System Monitor), robust detection must rely on behavioral context, Alternate Data Stream (ADS) monitoring, and kernel-execution attribution.
BTR.sys
is its reliance on Alternate Data Streams for configuration. Sysmon telemetry (Event ID 15) captures this behavior with high fidelity.
:changelist
on the driver file. Sysmon captures the encrypted RC4 payload directly in the Contents
field.BTR_CLI
): The tool directs the driver to write the feedback report into a secondary ADS on the driver itself (e.g., Random.sys:Random.dat
).MpEngine.dll
): The engine directs the driver to write the feedback report to a standalone file, typically in a protected path like C:\ProgramData\Microsoft\Windows Defender\Scans\RebootActions\
.FileCreateStreamHash
(Event ID 15) where TargetFilename
ends in .sys:changelist
. Secondarily, alert on .dat
streams created on .sys
files (specific to current PoC tool).BTR.sys
executes actions, for example, file deletion (Action 1), the operation occurs in Ring 0.
performing the deletion is recorded as System
(PID 4), not the user-mode tool that triggered it.System
(PID 4) deleting arbitrary files (especially security binaries) immediately following a DriverLoad
(Event ID 6) of a binary matching the BTR.sys
hash.BTR.sys
is dropped and registered by legitimate Windows Defender processes (e.g., MsMpEng.exe
).DriverLoad
(Event ID 6) where the Signature
is Microsoft Windows
and the Hashes
match known BTR.sys
versions, but the ParentImage
or Image
responsible for dropping the file is outside the Defender ecosystem (e.g., cmd.exe
, powershell.exe
, or unknown binaries).MpEngine.dll
): Uses the Service Control Manager (SCM) via CreateServiceW
. This generates standard Windows Event Logs (e.g., System Event ID 7045
– A service was installed).BTR_CLI
): Directly interacts with the Registry to create the service keys (HKLM\SYSTEM\CurrentControlSet\Services\{Random}
) and calls the undocumented NtLoadDriver
syscall. This bypasses SCM, meaning Event ID 7045
will not trigger.RegistryEvent
(Event ID 12/13) creating a service key where the Args
value contains :changelist
and Group
is set to Boot Bus Extender
, especially if unaccompanied by a standard Service Installation event.\SystemRoot\Temp\BootClean.log
by the System
(PID 4) process. This log creation is hardcoded in the driver and occurs regardless of the caller.BTR.sys
fundamentally relies on the attacker possessing SeLoadDriverPrivilege
. Enforcing the principle of least privilege and strictly monitoring the assignment and usage of this right is the primary defense.BTR.sys
. Defense-in-depth must include monitoring the context of driver loads and ADS creation, not just driver hashes.During our analysis across all collected samples and telemetry sources, we did not observe evidence of real-world abuse of BTR.sys
in the manner demonstrated in this research. This suggests the technique is currently unknown or unused by threat actors, making proactive detection engineering feasible before weaponization appears in the wild.
This research shows that the BTR.sys
driver, originally designed as a defensive remediation component, exposes a powerful and fully functional kernel-mode execution primitive when its internal protocol is understood. By reversing its encrypted transaction format, integrity validation scheme, and execution logic, we demonstrated that a trusted, signed Microsoft driver can be instructed to perform arbitrary file and registry operations from Ring 0 without exploiting any vulnerability.
The creation of the BTR_CLI
tool was a key milestone in validating our findings. The tool automates payload construction, encryption, integrity calculation, driver extraction, execution, and cleanup. This allowed us to reliably reproduce kernel-level operations across all tested Windows 7-11 versions and across every analyzed BTR.sys
build. Its successful operation confirmed that:
This effectively repurposes a specialized defensive component into a versatile, signed kernel-mode primitive capable of arbitrary file and registry manipulation.
More broadly, this work highlights an important defensive lesson: trusted security infrastructure can unintentionally expose attacker-usable primitives when its internal mechanisms are undocumented but reachable. The issue is not a vulnerability in the traditional sense, but rather an architectural trust boundary that can be crossed if an attacker already has administrative privileges.
Following responsible disclosure, MSRC confirmed that these findings do not meet the criteria for immediate servicing, as the technique relies on pre-existing administrative privileges (SeLoadDriverPrivilege
). This classification establishes BTR.sys
as a potent “Living-off-the-Land” driver (LOLDriver). Crucially, unlike third-party drivers often neutralized by the Microsoft Vulnerable Driver Blocklist or tracked by the LOLDrivers project, BTR.sys
is an essential, built-in Windows component. It remains fully allowed and operational, enabling advanced evasion without the risks or constraints associated with traditional BYOVD techniques.
As defenders increasingly rely on signed binaries as indicators of trust, research like this demonstrates why behavioral context, execution lineage, and intent analysis must complement signature-based trust models.
