Introduction
Once the attacker has breached the corporate network, subsequent stages of the attack often involve leveraging standard domain infrastructure protocols: using Kerberos, running DNS queries, accessing internal services, opening network shares, and other common networking actions. Because this activity is virtually indistinguishable from legitimate network traffic, it is extremely difficult to detect it with traditional network attack detection tools.
Kerberoasting and DNS tunneling have long ceased to be exotic techniques. They are becoming standard methods in modern attacks because they allow attackers to execute critical compromise stages while remaining undetected by traditional security tools. A clear example of this trend is seen in latest campaigns, employing both Kerberoasting and DNS tunneling.
Traditional network security tools perform well when the attack features a distinct and identifiable indicator: a characteristic query string, a known malicious traffic pattern, or the source code of an already discovered exploit. While this approach to threat detection remains effective, it cannot always be applied to discovering network attacks that blend seamlessly with legitimate traffic inside a corporate network.
Instead of searching for explicit indicators of attack, Network Anomaly Detection (NAD) analyzes all traffic for suspicious artifacts that deviate from the host’s typical network activity. Within Kaspersky’s solution portfolio, this technology is implemented specifically in the Kaspersky Anti Targeted Attack (KATA) platform.
The system analyzes network traffic data (DNS, DCE/RPC, Kerberos and other packets) and extracts key parameters used to identify anomalous behavior. This approach enables searching for attacks on domain controllers, signs of traffic tunneling and exfiltration, C2 communications, and other scenarios that may point to compromise of network infrastructure.
However, Network Anomaly Detection is not built on a single, universal set of indicators. Each attack scenario employs tailored detection models that account for the specifics of the corresponding network protocol, typical host behavior, and characteristic deviations from that baseline. This article examines two practical examples – detecting Kerberoasting and DNS tunneling – to demonstrate how these principles are implemented in KATA’s NAD rules and why this approach proves more effective than traditional signature-based analysis.
Kerberoasting attack detection by KATA
Why standard tools have a hard time detecting Kerberoasting
The Kerberoasting attack leverages the standard operational logic of the Kerberos protocol. The attacker identifies service accounts configured with a Service Principal Name (SPN), requests a Ticket-Granting Service (TGS) ticket for them, and attempts to crack the password offline using a dictionary attack against the retrieved ticket. If the password is weak or hasn’t been changed in a long time, the adversary can bruteforce it to get it in cleartext. Subsequently, these compromised credentials can be leveraged for both vertical and horizontal movement across the network.
The essence of a Kerberoasting attack is that an adversary possessing a compromised low-privileged account and a valid Ticket-Granting Ticket (TGT) for that account can request TGS tickets with weakened encryption for service accounts with SPNs. Crucially, it doesn’t matter whether the compromised account actually holds access permissions for those services. Having obtained these tickets, the attacker can then take them offline and bruteforce the service account’s password by trying to decrypt the corresponding ticket locally, without generating any network activity. As the encryption key is based on the password hash, the adversary can guess the password upon finding the correct key.
The attacker’s objective is to find a service account that has a simple password. Most likely, this will be an account created manually by the administrators of the infrastructure or a service. This is precisely why attackers are not interested in system service accounts with SPNs (such as CIFS/fileserver.company.local); these are generated automatically and feature highly complex passwords that are impossible to bruteforce.
We should note that the TGS ticket requests made by attackers are identical to standard, legitimate requests. Every domain naturally exhibits a high volume of Kerberos traffic. Therein lies the primary challenge of detecting Kerberoasting: legitimate service ticket requests (TGS-REQ) are indistinguishable from those issued by attackers. Consequently, the primary detection method relies on correlating indirect indicators rather than signature matching. Key indicators include an anomalous request source (atypical host or user account), a surge in requested SPNs within a short time window, attempts to obtain service tickets for sensitive or privileged service accounts, and off-hour timing or unusual request volume when benchmarked against the historical profile of both the user and the host.
Most of these indicators can be detected using NAD technology, which helps analysts cut through high volumes of Kerberos traffic to establish a concrete hypothesis: who initiated the Kerberoasting attack, which service accounts are at risk, and why this activity deviates from the baseline.
In the context of this attack, the network anomaly stems from a single host – likely using a single user account (cname
) – receiving TGS tickets ("msg_type": "KRB_TGS_REP"
) for numerous unique services with SPNs (sname
) within a short timeframe. These service accounts are non-system accounts.
To detect this anomaly, the NAD rule titled “Signs of a Kerberoasting attack” implements the following logic:
- From Kerberos network sessions during the search depth period, select only those with a successful Kerberos TGS-REP response, subject to the following conditions:
- The IP address that initiated the session must not be excluded in the
excl_sip
variable. - The requesting client name (
cname
) must not be included in the excluded users list (excl_users
variable). - The SPN (
sname
) must not be excluded within the rule. System SPNs are omitted from detection logic because they exist across most corporate environments and hold no interest for adversaries in this attack vector; including them in the total count of unique SPNs could lead to predefined threshold being exceeded, triggering false positives.
- The IP address that initiated the session must not be excluded in the
- Extract the
cname
(the name of the client requesting the TGS-REQ) andsname
(SPN itself) from these qualifying sessions. - Group the sessions by the source IP address and client account name (
cname
), while aggregating sessions with unique SPNs. - Generate an alert if a single IP address using a single client account receives TGS-REP responses for N unique SPN names within the specified search depth window, where N equals or exceeds the threshold variable
count_spns
. - Within the event regeneration window, group under the initial alert all subsequent alerts associated with the same client IP address. This avoids creating duplicate event records by incrementing the aggregation counter (Total appearances).
We should note that this type of logic cannot be implemented using IDS signatures. Consider creating a Suricata rule designed to detect Kerberos TGS-REP packets. To minimize false positives, we’ll exclude system SPNs (which carry highly complex passwords) and apply a threshold for the number of responses a single client can receive. However, such a rule cannot evaluate the uniqueness of the requested SPNs; it can only track packet counts. As a result, this signature would produce a high volume of false positives because any domain naturally generates large amounts of identical legitimate TGS-REP messages.
Furthermore, adding exclusions and tuning thresholds to fit your specific infrastructure environments is significantly more practical when managed through user variables in the interface rather than directly modifying the underlying structure of the IDS rule itself.
Creating a Network Anomaly Detection rule
Network Anomaly Detection (NAD) rules are written as SQL queries executed against KATA’s ClickHouse database. Below, we demonstrate how to add and deploy a rule.
To begin working with NAD rules, navigate to the “Custom rules” section of the interface and select “Intrusion detection”. Under the “Network Anomaly Detection” tab, you can create a new rule.
When adding a new rule, an analyst can select an appropriate rule template from the prebuilt set supplied with product updates. They can also manually modify the rule added from the template (converting it to a custom rule while keeping the original template intact) or author a rule from scratch using the provided guide.
Upon selecting a template, the analyst can review the rule description and either adjust or leave the default values for the following settings:
- Search depth (the lookback window over which the SQL query will run)
- Schedule (the execution frequency for running the query against the specified search depth)
- Event regeneration period (the timeframe during which identical alerts will be aggregated into a single record rather than displayed as distinct events)
To ensure the rule functions correctly, we recommend navigating to the “SQL-specific query” tab before deployment to review the variables used within the rule – a description for each variable is available by hovering over the question mark icon.
The variables are lists of IP addresses, dates, strings or numeric values that define the network infrastructure – such as domain controllers, DNS servers, time ranges, critical segments, and other entities. This allows you to tailor each rule to different network environments and incorporate specific infrastructure characteristics without modifying the underlying logic.
In our example, using variables allows you to adjust the “Signs of a Kerberoasting attack” rule as follows without altering the underlying SQL query:
- Exclude the source IP address of the TGS-REQ requests from the scope of detection logic (you can specify a single address, a subnet mask, or a dictionary containing addresses and subnets) as well as the requesting client account (accepts a single value or a dictionary with multiple values).
- Adjust the threshold value required to trigger an alert based on the number of unique SPNs in the TGS-REQ messages.
On this same page, you can test if the rule is functional prior to saving it.
When this rule triggers, an NDR:NAD
alert is generated. In the alert card, the analyst can review basic information: IP addresses, ports, and participating network endpoints.
From there, the analyst can navigate to the associated event, which provides a detailed breakdown of the anomaly alongside links to the affected hosts.
If needed, the analyst can view and export the network sessions associated with the alert. These sessions can be accessed directly from the alert or within the event card via the “Show related” drop-down list.
Within an individual session, the analyst can inspect standard details including interacting parties, data volume sent and received, and other fields and metrics. On the “Attributes” tab, the analyst can review the specific events recorded within that session.
Detecting DNS tunneling in KATA
How DNS tunnels work
DNS tunneling is a technique used to transmit data or control malware through firewalls by encoding information within DNS protocol requests and responses. Instead of performing standard name resolution, an infected host transmits data encoded within subdomain strings and receives response data via DNS records. This covert channel can be leveraged for C2 communication, bypassing network restrictions, or data exfiltration.
One method of implementing DNS tunneling involves utilizing TXT records. In this scenario, the client issues DNS TXT record queries for domain names where the right-hand portion of the domain name (the higher-level domains) remains static, while the left-hand portion (the lowest-level subdomain) carries encoded or encrypted data sent from the client to the server. Under this structure, a sample domain name might look like ZFcABQAIBA[.]testlab[.]local
, where testlab[.]local
serves as the static right-hand portion and ZFcABQAIBA
represents the variable left-hand string containing the data transmitted by the client.
In response to these queries, the server delivers commands or messages inside the data field of the TXT response. Because the right-hand portion of the domain name remains static, all client queries are consistently routed to the same C2 server, even if the intermediate DNS resolvers targeted by the client change.
It is rather challenging to identify this malicious activity within DNS traffic without generating false positives. DNS traffic is permitted across almost all corporate networks, long domain names occur routinely in both internal and external environments, and TXT records are frequently leveraged for legitimate operational purposes.
Suspicion is established through a combination of indicators: a high volume of long, seemingly random subdomains associated with a single top-level domain, high request frequency, an unusually large number of unique names, non-standard record types, and significant data transfer volumes within a single DNS session.
By analyzing DNS traffic for threat detection, we identified three primary fields of interest:
- Requested DNS name
- DNS record type
- TXT data field within the response
As shown in the image above, all of these fields are present in the DNS response. In a real-world scenario, a tunnel of this nature will transmit a volume of data that is abnormally large compared to standard DNS traffic.
Thus, in the context of DNS tunneling, a network anomaly occurs when 1) a single query source host sends data embedded in the variable left-hand portion of domain names (rrname
) while 2) maintaining a static right-hand portion (rrname
) and 3) receives DNS server responses containing TXT records (rtype
) with varying data (rdata
), while 4) the total volume of data transmitted in the left-hand portion of the requested domain name together with the TXT data response (rdata
+ rrname
) exceeds a predefined threshold.
When detecting DNS tunneling, the following nuances must be considered:
- A single tunnel will not be constrained to a single DNS session; data may be transmitted across multiple sessions with the DNS server, or each individual request may occur within a separate session.
- A client DNS query can contain more than one requested domain name.
- A DNS response can contain multiple TXT records, as well as a large volume of various non-TXT record types.
- Traffic between DNS servers must be excluded, as it duplicates client requests and can trigger false positives.
- Although the factors outlined above (an abnormally large or frequently changing left-hand subdomain alongside a static right-hand domain, or an unusually long string in a TXT record) serve as key indicators of DNS tunneling, they can also occur within legitimate network traffic.
These challenges create a high likelihood of false positives when detecting DNS tunneling, particularly when using IDS-based tools. Writing an accurate IDS rule for this type of activity is practically impossible. With rare exceptions, DNS tunneling tools possess static markers that can be leveraged for signature-based detection. However, in the absence of such markers, signature methods fail to deliver high detection accuracy without generating an overwhelming number of false positives. In these cases, a comprehensive approach combining multiple correlated indicators is essential to improve overall detection quality.
DNS tunneling detection logic
To add a rule for detecting this anomaly, you can use the prebuilt “DNS data tunneling via TXT records” template in the new rule creation interface. The “SQL-specific query” tab will display the list of variables used:
user_DNS_servers
: a list of internal DNS server addresses within the infrastructure, required for the rule to function correctly and minimize potential false positivesexcl_sip
: IP addresses to be excluded from the scope of the rule (you can specify a single address, a subnet mask, or a list containing both addresses and subnets)traffic_size
: the threshold value for the total volume of data (in bytes) transmitted through the tunnel
The detection logic for this network anomaly is structured as follows:
- From network sessions using the DNS protocol within the timeframe defined by the rule’s search depth, select only those sessions containing at least one TXT response.
Additionally:- The IP address that initiated the session must not be excluded in the
excl_sip
variable. - The source IP address that initiated the session must not belong to the internal DNS servers listed in the
user_DNS_servers
variable. - The DNS names requested by the client must not be excluded within the rule.
- The IP address that initiated the session must not be excluded in the
- Split qualifying DNS sessions into individual log lines, each corresponding to an individual request or response. Retain only DNS responses containing TXT data.
- Extract DNS names and their associated TXT data from these DNS responses. Retain only unique values.
- Group all resulting records by the session’s source IP address, aggregating all unique DNS names and TXT data blocks.
- Generate an alert if the combined size (in bytes) of the unique DNS names and TXT response data for a single IP address within the search depth window exceeds the specified threshold (the
traffic_size
parameter). - Within the event regeneration window, group under the initial alert all subsequent alerts associated with the same client IP address. This avoids creating duplicate event records by incrementing the aggregation counter (Total appearances).
The primary value of NAD technology in this scenario lies in noise reduction – by minimizing false positives – and faster investigation times. A DNS tunnel rarely presents itself as a single, blatantly malicious request. Instead, it leaves behind a behavioral footprint: repetition, length, domain structure, unusual record types, numerous subdomains branching off an unchanging root domain, and anomalous host behavior. KATA consolidates these indicators into a single alert, presenting the analyst with an actionable attack hypothesis rather than a set of fragmented DNS events.
Prebuilt rules for detecting network anomalies in KATA
KATA users should note that Network Anomaly Detection (NAD) rules are not enabled by default. Rules must be added manually using the procedure described in the preceding sections. This design ensures that analysts can fine-tune rules to fit specific network infrastructures using variables.
Analysts have three ways of creating new rules:
- Adding a rule from a prebuilt template and adjusting custom variables. In this case, the rule is classified as a system rule.
- Adding a rule from a prebuilt template and modifying its underlying SQL query (which requires enabling the “Unlock all template values” option) to create a custom rule based on the template. When modified this way, the rule transitions from a system rule to a custom rule.
- Authoring a custom rule from scratch, which requires a basic understanding of ClickHouse SQL queries and familiarity with the product documentation.
As of this publication, the product ships with 59 prebuilt NAD rule templates (with additional templates delivered via product updates). KATA supports running up to 200 active rules simultaneously.
Prebuilt rules are divided into six categories:
- Large Data Transfers: tracking abnormally large network sessions across various protocols during regular hours, at night, or over weekends.
- Suspicious Connections: detecting suspicious connections that may indicate hazardous activity, shadow IT, evasion of attack detection mechanisms, and other threats.
- Domain Attacks: detecting classic attacks targeting domain network infrastructures using offensive tooling.
- Reconnaissance Activity: identifying suspicious activity within domain protocol sessions (Kerberos, DCE/RPC, LDAP, DNS) resembling domain reconnaissance.
- Connections to Suspicious Resources: detects actions that violate security policies, potential data exfiltration beyond the perimeter, and unauthorized internet access originating from secured network segments.
- C2 Communication: identifies network sessions characteristic of a potential C2 communication channel or tunnel.
The table below lists the rule templates for detecting network anomalies in KATA:
| Rule category | Rule name | Protocols used |
| Large Data Transfers | Data tunneling in DNS traffic | DNS |
| ICMP, TCP, UDP, RDP, SSH or LDAP sessions with a large volume of traffic (6 rules) | ICMP, TCP, UDP, RDP, SSH, or LDAP (depends on selected rule) | |
| ICMP, TCP, UDP, RDP, SSH or LDAP sessions with a large volume of traffic at nighttime (6 rules) | ICMP, TCP, UDP, RDP, SSH, or LDAP (depends on selected rule) | |
| ICMP, TCP, UDP, RDP, SSH or LDAP sessions with a large volume of traffic on non-working days (6 rules) | ICMP, TCP, UDP, RDP, SSH, or LDAP (depends on selected rule) | |
| Suspicious Connections | Queries to unknown DNS servers | DNS |
| Use of unauthorized routes | TCP, UDP | |
| Use of suspicious ports for connections to external addresses | TCP, UDP | |
| Use of non-typical protocols for connections | TCP, UDP, HTTP, HTTPS, DNS, SMTP | |
| Inconsistencies with firewall configuration | TCP, UDP | |
| Use of unauthorized ports for RDP or SSH sessions (2 rules) | RDP or SSH (depends on selected rule) | |
| Interactions with external IP addresses over the RDP or SSH protocol (2 rules) | RDP or SSH (depends on selected rule) | |
| Suspicious RDP sessions with domain controllers | RDP | |
| Connection to an unknown server via Kaspersky Security Center ports | TCP, UDP | |
| Domain Attacks | Signs of a DCSync attack | DCE/RPC |
| Signs of a DCShadow attack | DCE/RPC | |
| Signs of DHCP spoofing | DHCP | |
| DNS queries to Canarytoken domains | DNS | |
| Signs of a Kerberoasting attack | Kerberos | |
| Signs of an AS-REP Roasting attack | Kerberos | |
| Signs of a brute-force password attack on SSH | SSH | |
| Signs of SOAPHound usage | LDAP | |
| Large-volume Active Directory object data collection via LDAP queries | LDAP | |
| Reconnaissance Activity | Getting information about a task in the Task Scheduler | DCE/RPC |
| Getting a list of Kerberos users | Kerberos | |
| LDAP queries to rights delegation attribute | LDAP | |
| LDAP queries to attribute for getting administrator passwords | LDAP | |
| Signs of an internal horizontal port scan | TCP, UDP | |
| Signs of an internal vertical port scan | TCP, UDP | |
| DNS zone data replication requests sent from sources other than DNS servers | DNS | |
| Successfully completed requests for DNS zone data replication sent from sources other than DNS servers | DNS | |
| LDAP query targeting a critical attribute of insecure credentials | LDAP | |
| Enumeration of domain accounts via LDAP queries | LDAP | |
| Exceeding the threshold for requested critical attributes in LDAP queries | LDAP | |
| LDAP search queries containing a high number of critical attributes | LDAP | |
| Connections to Suspicious Resources | Queries to unauthorized domain names | DNS |
| Transmission of large data volumes to cloud storages | TCP, UDP, DNS | |
| Connections to cloud storages or file transfer services | TCP, DNS | |
| Connections to public repositories | TCP, DNS | |
| Connections to resources of programs for traffic tunneling | TCP, DNS | |
| С2 Communication | Possible queries to DGA domains | DNS |
| DNS data tunneling via TXT records | DNS | |
| Numerous blocked connections to external addresses | TCP, UDP |
Conclusion
The examples of Kerberoasting and DNS tunneling clearly demonstrate why modern security defenses cannot rely solely on looking for known signatures and indicators of compromise. Both attack techniques abuse protocols that operate inside corporate networks every day. At the individual event level, they may look like legitimate activity, yet in behavioral context, they stand out as clear indicators of compromise.
NAD directly addresses this gap. Instead of relying purely on signature matches across Kerberos or DNS traffic, it highlights deviations from established baselines: who initiated the activity, how frequently it recurred, which services or domains were targeted, and why that matters for a specific infrastructure.
As a result, analysts gain a clear, actionable starting point for investigation. This capability is especially valuable for spotting the signs of APT group activity, which runs stealthily and is designed to blend in with legitimate operations. The importance of this capability will only grow: as attack techniques evolve, detecting suspicious activity at its earliest stages – before it escalates into critical service compromise or a data breach – becomes increasingly vital.
Network Anomaly Detection in KATA
